ABB SACE FORMULA Circuit Breakers

ABB SACE FORMULA moulded-case circuit breakers are used in low-voltage distribution and equipment protection. The existing model table on this page contains FORMULA A references with A1, A2 and A3 frames. Other FORMULA portfolio names shown on the page are separate product groups and must not be assigned the A-series ratings or accessories.

Formula Series

Key Features

What the existing list covers

The table retains 397 FORMULA A references: 253 A1, 104 A2 and 40 A3 entries. ABB’s SACE FORMULA brochure describes A1, A2 and A3 fixed-version frames with front terminals. Their frame size, pole options and protection characteristics differ; the largest family rating is not the rating of every listed breaker.

ABB separately documents FORMULA ATM, DSP, BLD and DSA portfolios. The existing portfolio-name examples are retained, but those families are not mixed into the technical definition of the A1/A2/A3 lookup table. No interchangeability between these products is implied.

Protection and selection boundaries

  • Identify the circuit, load current and required overload and short-circuit protection.
  • Confirm operating voltage and AC or DC use. Breaking capacity must be checked at the actual voltage and for the exact performance level.
  • Specify frame, rated current, pole count and neutral requirements where applicable.
  • Confirm the complete trip-unit designation and settings. The table includes TMF, MF and ELT references; do not assume identical protection functions or adjustment ranges.
  • For references with residual-current or other assembly suffixes, check the complete assembly documentation, auxiliary supply and application rather than treating the base breaker alone as sufficient.
  • Verify terminals, installation dimensions, operating handle, required releases and the exact accessory reference.

Standards and version documentation

ABB’s brochure presents ratings under stated voltage and pole conditions. IEC and UL or regional variants must be evaluated using their applicable documents. A frame rating, Icu value or accessory from one family cannot be assigned to all FORMULA products.

Historical names, codes and existing assembly references remain in the table. Unconfirmed detailed parameters should be checked against the full model, nameplate and current applicable ABB technical information, without assuming a historical error, version change or replacement.

Information for quotation

Send the full product model, ABB Order Code or Article Number, quantity and destination country. Include circuit voltage, required current, poles, trip-unit details, short-circuit requirement and accessories. For existing equipment, add nameplate photos and installation/terminal details. Product status and current availability should be confirmed before ordering.

Browse Moulded Case Circuit Breakers or Contact. Official reference: ABB SACE FORMULA A1/A2/A3 brochure. Other portfolio identities can be checked in ABB’s regional circuit-breaker overview. The original PDF below is retained.

Popular Models

Formula A Series
Formula ATM Series
Formula DSP Series
Formula BLD Series

ABB Formula Series Complete Model List

397 models shown
Product ModelOrder Code / Article No.Series
A1A125 MF100/1200 FF 3P2TFG100097R1001Formula A
A1A125 MF32/384 FF 3P2TFG100091R1001Formula A
A1A125 MF40/480 FF 3P2TFG100092R1001Formula A
A1A125 MF50/600 FF 3P2TFG100093R1001Formula A
A1A125 MF60/720 FF 3P2TFG100094R1001Formula A
A1A125 MF70/840 FF 3P2TFG100095R1001Formula A
A1A125 MF80/960 FF 3P2TFG100096R1001Formula A
A1A125 TMF100/1000 FF 3P1SDA066520R1Formula A
A1A125 TMF100/1000 FF 4P1SDA066534R1Formula A
A1A125 TMF125/1250 FF 3P1SDA066521R1Formula A
A1A125 TMF125/1250 FF 4P1SDA066535R1Formula A
A1A125 TMF15/400 FF 3P1SDA066510R1Formula A
A1A125 TMF15/400 FF 4P1SDA066524R1Formula A
A1A125 TMF16/400 FF 3P1SDA068746R1Formula A
A1A125 TMF16/400 FF 4P1SDA068750R1Formula A
A1A125 TMF20/400 FF 3P1SDA066511R1Formula A
A1A125 TMF20/400 FF 4P1SDA066525R1Formula A
A1A125 TMF25/400 FF 3P1SDA066512R1Formula A
A1A125 TMF25/400 FF 4P1SDA066526R1Formula A
A1A125 TMF30/400 FF 3P1SDA066513R1Formula A
A1A125 TMF30/400 FF 4P1SDA066527R1Formula A
A1A125 TMF32/400 FF 3P1SDA068757R1Formula A
A1A125 TMF32/400 FF 4P1SDA068761R1Formula A
A1A125 TMF40/400 FF 3P1SDA066514R1Formula A
A1A125 TMF40/400 FF 4P1SDA066528R1Formula A
A1A125 TMF50/500 FF 3P1SDA066515R1Formula A
A1A125 TMF50/500 FF 4P1SDA066529R1Formula A
A1A125 TMF60/600 FF 3P1SDA066516R1Formula A
A1A125 TMF60/600 FF 3P (OEM Mach-indus)2TFG100081R1001Formula A
A1A125 TMF60/600 FF 4P1SDA066530R1Formula A
A1A125 TMF63/630 FF 3P1SDA068768R1Formula A
A1A125 TMF63/630 FF 4P1SDA068772R1Formula A
A1A125 TMF70/700 FF 3P1SDA066517R1Formula A
A1A125 TMF70/700 FF 4P1SDA066531R1Formula A
A1A125 TMF80/800 FF 3P1SDA066518R1Formula A
A1A125 TMF80/800 FF 3P (OEM Mach-indus)2TFG100082R1001Formula A
A1A125 TMF80/800 FF 4P1SDA066532R1Formula A
A1A125 TMF90/900 FF 3P1SDA066519R1Formula A
A1A125 TMF90/900 FF 4P1SDA066533R1Formula A
A1B125 MF100/1200 FF 3P2TFG100104R1001Formula A
A1B125 MF32/384 FF 3P2TFG100098R1001Formula A
A1B125 MF40/480 FF 3P2TFG100099R1001Formula A
A1B125 MF50/600 FF 3P2TFG100100R1001Formula A
A1B125 MF60/720 FF 3P2TFG100101R1001Formula A
A1B125 MF70/840 FF 3P2TFG100102R1001Formula A
A1B125 MF80/960 FF 3P2TFG100103R1001Formula A
A1B125 TMF100/1000 FF 3P1SDA066707R1Formula A
A1B125 TMF100/1000 FF 3P+RCD2TFE100239R1001Formula A
A1B125 TMF100/1000 FF 4P1SDA066743R1Formula A
A1B125 TMF100/1000 FF 4P+RCD2TFE100254R1001Formula A
A1B125 TMF125/1250 FF 3P1SDA066708R1Formula A
A1B125 TMF125/1250 FF 3P+RCD2TFE100240R1001Formula A
A1B125 TMF125/1250 FF 4P1SDA066744R1Formula A
A1B125 TMF125/1250 FF 4P+RCD2TFE100255R1001Formula A
A1B125 TMF15/400 FF 3P1SDA066697R1Formula A
A1B125 TMF15/400 FF 3P+RCD2TFE100226R1001Formula A
A1B125 TMF15/400 FF 4P1SDA066733R1Formula A
A1B125 TMF15/400 FF 4P+RCD2TFE100241R1001Formula A
A1B125 TMF16/400 FF 3P1SDA068747R1Formula A
A1B125 TMF16/400 FF 3P+RCD2TFE100227R1001Formula A
A1B125 TMF16/400 FF 4P1SDA068751R1Formula A
A1B125 TMF16/400 FF 4P+RCD2TFE100242R1001Formula A
A1B125 TMF20/400 FF 3P1SDA066698R1Formula A
A1B125 TMF20/400 FF 3P+RCD2TFE100228R1001Formula A
A1B125 TMF20/400 FF 4P1SDA066734R1Formula A
A1B125 TMF20/400 FF 4P+RCD2TFE100243R1001Formula A
A1B125 TMF25/400 FF 3P1SDA066699R1Formula A
A1B125 TMF25/400 FF 3P+RCD2TFE100229R1001Formula A
A1B125 TMF25/400 FF 4P1SDA066735R1Formula A
A1B125 TMF25/400 FF 4P+RCD2TFE100244R1001Formula A
A1B125 TMF30/400 FF 3P1SDA066700R1Formula A
A1B125 TMF30/400 FF 3P+RCD2TFE100230R1001Formula A
A1B125 TMF30/400 FF 4P1SDA066736R1Formula A
A1B125 TMF30/400 FF 4P+RCD2TFE100245R1001Formula A
A1B125 TMF32/400 FF 3P1SDA068758R1Formula A
A1B125 TMF32/400 FF 3P+RCD2TFE100231R1001Formula A
A1B125 TMF32/400 FF 4P1SDA068762R1Formula A
A1B125 TMF32/400 FF 4P+RCD2TFE100246R1001Formula A
A1B125 TMF40/400 FF 3P1SDA066701R1Formula A
A1B125 TMF40/400 FF 3P+RCD2TFE100232R1001Formula A
A1B125 TMF40/400 FF 4P1SDA066737R1Formula A
A1B125 TMF40/400 FF 4P+RCD2TFE100247R1001Formula A
A1B125 TMF50/500 FF 3P1SDA066702R1Formula A
A1B125 TMF50/500 FF 3P+RCD2TFE100233R1001Formula A
A1B125 TMF50/500 FF 4P1SDA066738R1Formula A
A1B125 TMF50/500 FF 4P+RCD2TFE100248R1001Formula A
A1B125 TMF60/600 FF 3P1SDA066703R1Formula A
A1B125 TMF60/600 FF 3P+RCD2TFE100234R1001Formula A
A1B125 TMF60/600 FF 4P1SDA066739R1Formula A
A1B125 TMF60/600 FF 4P+RCD2TFE100249R1001Formula A
A1B125 TMF63/630 FF 3P1SDA068769R1Formula A
A1B125 TMF63/630 FF 3P+RCD2TFE100235R1001Formula A
A1B125 TMF63/630 FF 4P1SDA068773R1Formula A
A1B125 TMF63/630 FF 4P+RCD2TFE100250R1001Formula A
A1B125 TMF70/700 FF 3P1SDA066704R1Formula A
A1B125 TMF70/700 FF 3P+RCD2TFE100236R1001Formula A
A1B125 TMF70/700 FF 4P1SDA066740R1Formula A
A1B125 TMF70/700 FF 4P+RCD2TFE100251R1001Formula A
A1B125 TMF80/800 FF 3P1SDA066705R1Formula A
A1B125 TMF80/800 FF 3P+RCD2TFE100237R1001Formula A
A1B125 TMF80/800 FF 4P1SDA066741R1Formula A
A1B125 TMF80/800 FF 4P+RCD2TFE100252R1001Formula A
A1B125 TMF90/900 FF 3P1SDA066706R1Formula A
A1B125 TMF90/900 FF 3P+RCD2TFE100238R1001Formula A
A1B125 TMF90/900 FF 4P1SDA066742R1Formula A
A1B125 TMF90/900 FF 4P+RCD2TFE100253R1001Formula A
A1C125 MF100/1200 FF 3P2TFG100111R1001Formula A
A1C125 MF32/384 FF 3P2TFG100105R1001Formula A
A1C125 MF40/480 FF 3P2TFG100106R1001Formula A
A1C125 MF50/600 FF 3P2TFG100107R1001Formula A
A1C125 MF60/720 FF 3P2TFG100108R1001Formula A
A1C125 MF70/840 FF 3P2TFG100109R1001Formula A
A1C125 MF80/960 FF 3P2TFG100110R1001Formula A
A1C125 TMF 100/1000 FF 3P - WHPSB11SDA066719R1Formula A
A1C125 TMF 100/1000 FF 4P - WHPSB21SDA066755R1Formula A
A1C125 TMF 125/1250 FF 3P - WHPSB31SDA066720R1Formula A
A1C125 TMF 125/1250 FF 3P - WHPSB71SDA066720R1Formula A
A1C125 TMF 125/1250 FF 4P - WHPSB41SDA066756R1Formula A
A1C125 TMF100/1000 F F 3P-DVP-WHPSB11SDA083119R1Formula A
A1C125 TMF100/1000 F F 3P-DVP-WHPSB71SDA083119R1Formula A
A1C125 TMF100/1000 F F 4P-DVP-WHPSB21SDA083167R1Formula A
A1C125 TMF100/1000 F F 4P-DVP-WHPSB81SDA083167R1Formula A
A1C125 TMF100/1000 FF 3P1SDA066719R1Formula A
A1C125 TMF100/1000 FF 3P+RCD2TFE100279R1001Formula A
A1C125 TMF100/1000 FF 4P1SDA066755R1Formula A
A1C125 TMF100/1000 FF 4P+RCD2TFE100294R1001Formula A
A1C125 TMF125/1250 F F 3P-DVP-WHPSB31SDA083120R1Formula A
A1C125 TMF125/1250 F F 3P-DVP-WHPSB91SDA083120R1Formula A
A1C125 TMF125/1250 F F 4P-DVP-WHPSB101SDA083168R1Formula A
A1C125 TMF125/1250 F F 4P-DVP-WHPSB41SDA083168R1Formula A
A1C125 TMF125/1250 FF 3P1SDA066720R1Formula A
A1C125 TMF125/1250 FF 3P+RCD2TFE100280R1001Formula A
A1C125 TMF125/1250 FF 4P1SDA066756R1Formula A
A1C125 TMF125/1250 FF 4P+RCD2TFE100295R1001Formula A
A1C125 TMF15/400 FF 3P1SDA066709R1Formula A
A1C125 TMF15/400 FF 3P+RCD2TFE100266R1001Formula A
A1C125 TMF15/400 FF 4P1SDA066745R1Formula A
A1C125 TMF15/400 FF 4P+RCD2TFE100281R1001Formula A
A1C125 TMF16/400 FF 3P1SDA068748R1Formula A
A1C125 TMF16/400 FF 3P+RCD2TFE100267R1001Formula A
A1C125 TMF16/400 FF 4P1SDA068752R1Formula A
A1C125 TMF16/400 FF 4P+RCD2TFE100282R1001Formula A
A1C125 TMF20/400 FF 3P1SDA066710R1Formula A
A1C125 TMF20/400 FF 3P+RCD2TFE100268R1001Formula A
A1C125 TMF20/400 FF 4P1SDA066746R1Formula A
A1C125 TMF20/400 FF 4P+RCD2TFE100283R1001Formula A
A1C125 TMF25/400 FF 3P1SDA066711R1Formula A
A1C125 TMF25/400 FF 3P+RCD2TFE100269R1001Formula A
A1C125 TMF25/400 FF 4P1SDA066747R1Formula A
A1C125 TMF25/400 FF 4P+RCD2TFE100284R1001Formula A
A1C125 TMF30/400 FF 3P1SDA066712R1Formula A
A1C125 TMF30/400 FF 3P+RCD2TFE100270R1001Formula A
A1C125 TMF30/400 FF 4P1SDA066748R1Formula A
A1C125 TMF30/400 FF 4P+RCD2TFE100285R1001Formula A
A1C125 TMF32/400 FF 3P1SDA068759R1Formula A
A1C125 TMF32/400 FF 3P+RCD2TFE100271R1001Formula A
A1C125 TMF32/400 FF 4P1SDA068763R1Formula A
A1C125 TMF32/400 FF 4P+RCD2TFE100286R1001Formula A
A1C125 TMF40/400 FF 3P1SDA066713R1Formula A
A1C125 TMF40/400 FF 3P+RCD2TFE100272R1001Formula A
A1C125 TMF40/400 FF 4P1SDA066749R1Formula A
A1C125 TMF40/400 FF 4P+RCD2TFE100287R1001Formula A
A1C125 TMF50/500 FF 3P1SDA066714R1Formula A
A1C125 TMF50/500 FF 3P+RCD2TFE100273R1001Formula A
A1C125 TMF50/500 FF 4P1SDA066750R1Formula A
A1C125 TMF50/500 FF 4P+RCD2TFE100288R1001Formula A
A1C125 TMF60/600 FF 3P1SDA066715R1Formula A
A1C125 TMF60/600 FF 3P+RCD2TFE100274R1001Formula A
A1C125 TMF60/600 FF 4P1SDA066751R1Formula A
A1C125 TMF60/600 FF 4P+RCD2TFE100289R1001Formula A
A1C125 TMF63/630 FF 3P1SDA068770R1Formula A
A1C125 TMF63/630 FF 3P+RCD2TFE100275R1001Formula A
A1C125 TMF63/630 FF 4P1SDA068774R1Formula A
A1C125 TMF63/630 FF 4P+RCD2TFE100290R1001Formula A
A1C125 TMF70/700 FF 3P1SDA066716R1Formula A
A1C125 TMF70/700 FF 3P+RCD2TFE100276R1001Formula A
A1C125 TMF70/700 FF 4P1SDA066752R1Formula A
A1C125 TMF70/700 FF 4P+RCD2TFE100291R1001Formula A
A1C125 TMF80/800 FF 3P1SDA066717R1Formula A
A1C125 TMF80/800 FF 3P+RCD2TFE100277R1001Formula A
A1C125 TMF80/800 FF 4P1SDA066753R1Formula A
A1C125 TMF80/800 FF 4P+RCD2TFE100292R1001Formula A
A1C125 TMF90/900 FF 3P1SDA066718R1Formula A
A1C125 TMF90/900 FF 3P+RCD2TFE100278R1001Formula A
A1C125 TMF90/900 FF 4P1SDA066754R1Formula A
A1C125 TMF90/900 FF 4P+RCD2TFE100293R1001Formula A
A1N125 MF100/1200 FF 3P2TFG100118R1001Formula A
A1N125 MF32/384 FF 3P2TFG100112R1001Formula A
A1N125 MF40/480 FF 3P2TFG100113R1001Formula A
A1N125 MF50/600 FF 3P2TFG100114R1001Formula A
A1N125 MF60/720 FF 3P2TFG100115R1001Formula A
A1N125 MF70/840 FF 3P2TFG100116R1001Formula A
A1N125 MF80/960 FF 3P2TFG100117R1001Formula A
A1N125 TMF100/1000 FF 3P1SDA066731R1Formula A
A1N125 TMF100/1000 FF 3P+RCD2TFE100319R1001Formula A
A1N125 TMF100/1000 FF 4P1SDA066767R1Formula A
A1N125 TMF100/1000 FF 4P+RCD2TFE100334R1001Formula A
A1N125 TMF125/1250 FF 3P1SDA066732R1Formula A
A1N125 TMF125/1250 FF 3P+RCD2TFE100320R1001Formula A
A1N125 TMF125/1250 FF 4P1SDA066768R1Formula A
A1N125 TMF125/1250 FF 4P+RCD2TFE100335R1001Formula A
A1N125 TMF15/400 FF 3P1SDA066721R1Formula A
A1N125 TMF15/400 FF 3P+RCD2TFE100306R1001Formula A
A1N125 TMF15/400 FF 4P1SDA066757R1Formula A
A1N125 TMF15/400 FF 4P+RCD2TFE100321R1001Formula A
A1N125 TMF16/400 FF 3P1SDA068749R1Formula A
A1N125 TMF16/400 FF 3P+RCD2TFE100307R1001Formula A
A1N125 TMF16/400 FF 4P1SDA068753R1Formula A
A1N125 TMF16/400 FF 4P+RCD2TFE100322R1001Formula A
A1N125 TMF20/400 FF 3P1SDA066722R1Formula A
A1N125 TMF20/400 FF 3P+RCD2TFE100308R1001Formula A
A1N125 TMF20/400 FF 4P1SDA066758R1Formula A
A1N125 TMF20/400 FF 4P+RCD2TFE100323R1001Formula A
A1N125 TMF25/400 FF 3P1SDA066723R1Formula A
A1N125 TMF25/400 FF 3P+RCD2TFE100309R1001Formula A
A1N125 TMF25/400 FF 4P1SDA066759R1Formula A
A1N125 TMF25/400 FF 4P+RCD2TFE100324R1001Formula A
A1N125 TMF30/400 FF 3P1SDA066724R1Formula A
A1N125 TMF30/400 FF 3P+RCD2TFE100310R1001Formula A
A1N125 TMF30/400 FF 4P1SDA066760R1Formula A
A1N125 TMF30/400 FF 4P+RCD2TFE100325R1001Formula A
A1N125 TMF32/400 FF 3P1SDA068760R1Formula A
A1N125 TMF32/400 FF 3P+RCD2TFE100311R1001Formula A
A1N125 TMF32/400 FF 4P1SDA068764R1Formula A
A1N125 TMF32/400 FF 4P+RCD2TFE100326R1001Formula A
A1N125 TMF40/400 FF 3P1SDA066725R1Formula A
A1N125 TMF40/400 FF 3P+RCD2TFE100312R1001Formula A
A1N125 TMF40/400 FF 4P1SDA066761R1Formula A
A1N125 TMF40/400 FF 4P+RCD2TFE100327R1001Formula A
A1N125 TMF50/500 FF 3P1SDA066726R1Formula A
A1N125 TMF50/500 FF 3P+RCD2TFE100313R1001Formula A
A1N125 TMF50/500 FF 4P1SDA066762R1Formula A
A1N125 TMF50/500 FF 4P+RCD2TFE100328R1001Formula A
A1N125 TMF60/600 FF 3P1SDA066727R1Formula A
A1N125 TMF60/600 FF 3P+RCD2TFE100314R1001Formula A
A1N125 TMF60/600 FF 4P1SDA066763R1Formula A
A1N125 TMF60/600 FF 4P+RCD2TFE100329R1001Formula A
A1N125 TMF63/630 FF 3P1SDA068771R1Formula A
A1N125 TMF63/630 FF 3P+RCD2TFE100315R1001Formula A
A1N125 TMF63/630 FF 4P1SDA068775R1Formula A
A1N125 TMF63/630 FF 4P+RCD2TFE100330R1001Formula A
A1N125 TMF70/700 FF 3P1SDA066728R1Formula A
A1N125 TMF70/700 FF 3P+RCD2TFE100316R1001Formula A
A1N125 TMF70/700 FF 4P1SDA066764R1Formula A
A1N125 TMF70/700 FF 4P+RCD2TFE100331R1001Formula A
A1N125 TMF80/800 FF 3P1SDA066729R1Formula A
A1N125 TMF80/800 FF 3P+RCD2TFE100317R1001Formula A
A1N125 TMF80/800 FF 4P1SDA066765R1Formula A
A1N125 TMF80/800 FF 4P+RCD2TFE100332R1001Formula A
A1N125 TMF90/900 FF 3P1SDA066730R1Formula A
A1N125 TMF90/900 FF 3P+RCD2TFE100318R1001Formula A
A1N125 TMF90/900 FF 4P1SDA066766R1Formula A
A1N125 TMF90/900 FF 4P+RCD2TFE100333R1001Formula A
A2B250 MF100/1200 FF 3P2TFG100121R1001Formula A
A2B250 MF125/1500 FF 3P2TFG100122R1001Formula A
A2B250 MF160/1920 FF 3P2TFG100123R1001Formula A
A2B250 MF200/2400 FF 3P2TFG100124R1001Formula A
A2B250 TMF125/1250 FF 3P1SDA066548R1Formula A
A2B250 TMF125/1250 FF 3P + RCD+CT1102TFE100346R1001Formula A
A2B250 TMF125/1250 FF 4P1SDA066554R1Formula A
A2B250 TMF125/1250 FF 4P + RCD+CT1102TFE100353R1001Formula A
A2B250 TMF150/1500 FF 3P1SDA068779R1Formula A
A2B250 TMF150/1500 FF 3P + RCD+CT1102TFE100347R1001Formula A
A2B250 TMF150/1500 FF 4P1SDA068782R1Formula A
A2B250 TMF150/1500 FF 4P + RCD+CT1102TFE100354R1001Formula A
A2B250 TMF160/1600 FF 3P1SDA066549R1Formula A
A2B250 TMF160/1600 FF 3P + RCD+CT1102TFE100348R1001Formula A
A2B250 TMF160/1600 FF 4P1SDA066555R1Formula A
A2B250 TMF160/1600 FF 4P + RCD+CT1102TFE100355R1001Formula A
A2B250 TMF175/1750 FF 3P1SDA066550R1Formula A
A2B250 TMF175/1750 FF 3P + RCD+CT1102TFE100349R1001Formula A
A2B250 TMF175/1750 FF 4P1SDA066556R1Formula A
A2B250 TMF175/1750 FF 4P + RCD+CT1102TFE100356R1001Formula A
A2B250 TMF200/2000 FF 3P1SDA066551R1Formula A
A2B250 TMF200/2000 FF 3P + RCD+CT1102TFE100350R1001Formula A
A2B250 TMF200/2000 FF 4P1SDA066557R1Formula A
A2B250 TMF200/2000 FF 4P + RCD+CT1102TFE100357R1001Formula A
A2B250 TMF225/2250 FF 3P1SDA066552R1Formula A
A2B250 TMF225/2250 FF 3P + RCD+CT1102TFE100351R1001Formula A
A2B250 TMF225/2250 FF 4P1SDA066558R1Formula A
A2B250 TMF225/2250 FF 4P + RCD+CT1102TFE100358R1001Formula A
A2B250 TMF250/2500 FF 3P1SDA066553R1Formula A
A2B250 TMF250/2500 FF 3P + RCD+CT1102TFE100352R1001Formula A
A2B250 TMF250/2500 FF 4P1SDA066559R1Formula A
A2B250 TMF250/2500 FF 4P + RCD+CT1102TFE100359R1001Formula A
A2C250 MF100/1200 FF 3P2TFG100125R1001Formula A
A2C250 MF125/1500 FF 3P2TFG100126R1001Formula A
A2C250 MF160/1920 FF 3P2TFG100127R1001Formula A
A2C250 MF200/2400 FF 3P2TFG100128R1001Formula A
A2C250 TMF 250/2500 FF 3P - WHPSB51SDA066780R1Formula A
A2C250 TMF 250/2500 FF 3P - WHPSB81SDA066780R1Formula A
A2C250 TMF 250/2500 FF 4P - WHPSB61SDA066792R1Formula A
A2C250 TMF 250/2500 FF 4P-WHPSB121SDA066792R1Formula A
A2C250 TMF125/1250 FF 3P1SDA066775R1Formula A
A2C250 TMF125/1250 FF 3P + RCD+CT1102TFE100370R1001Formula A
A2C250 TMF125/1250 FF 4P1SDA066787R1Formula A
A2C250 TMF125/1250 FF 4P + RCD+CT1102TFE100377R1001Formula A
A2C250 TMF150/1500 FF 3P1SDA068780R1Formula A
A2C250 TMF150/1500 FF 3P + RCD+CT1102TFE100371R1001Formula A
A2C250 TMF150/1500 FF 4P1SDA068783R1Formula A
A2C250 TMF150/1500 FF 4P + RCD+CT1102TFE100378R1001Formula A
A2C250 TMF160/1600 FF 3P1SDA066776R1Formula A
A2C250 TMF160/1600 FF 3P + RCD+CT1102TFE100372R1001Formula A
A2C250 TMF160/1600 FF 4P1SDA066788R1Formula A
A2C250 TMF160/1600 FF 4P + RCD+CT1102TFE100379R1001Formula A
A2C250 TMF175/1750 FF 3P1SDA066777R1Formula A
A2C250 TMF175/1750 FF 3P + RCD+CT1102TFE100373R1001Formula A
A2C250 TMF175/1750 FF 4P1SDA066789R1Formula A
A2C250 TMF175/1750 FF 4P + RCD+CT1102TFE100380R1001Formula A
A2C250 TMF200/2000 FF 3P1SDA066778R1Formula A
A2C250 TMF200/2000 FF 3P + RCD+CT1102TFE100374R1001Formula A
A2C250 TMF200/2000 FF 4P1SDA066790R1Formula A
A2C250 TMF200/2000 FF 4P + RCD+CT1102TFE100381R1001Formula A
A2C250 TMF225/2250 FF 3P1SDA066779R1Formula A
A2C250 TMF225/2250 FF 3P + RCD+CT1102TFE100375R1001Formula A
A2C250 TMF225/2250 FF 4P1SDA066791R1Formula A
A2C250 TMF225/2250 FF 4P + RCD+CT1102TFE100382R1001Formula A
A2C250 TMF250/2500 F F 3P-DVP-WHPSB111SDA083216R1Formula A
A2C250 TMF250/2500 F F 3P-DVP-WHPSB51SDA083216R1Formula A
A2C250 TMF250/2500 F F 4P-DVP-WHPSB121SDA083234R1Formula A
A2C250 TMF250/2500 F F 4P-DVP-WHPSB61SDA083234R1Formula A
A2C250 TMF250/2500 FF 3P1SDA066780R1Formula A
A2C250 TMF250/2500 FF 3P + RCD+CT1102TFE100376R1001Formula A
A2C250 TMF250/2500 FF 4P1SDA066792R1Formula A
A2C250 TMF250/2500 FF 4P + RCD+CT1102TFE100383R1001Formula A
A2N250 MF100/1200 FF 3P2TFG100129R1001Formula A
A2N250 MF125/1500 FF 3P2TFG100130R1001Formula A
A2N250 MF160/1920 FF 3P2TFG100131R1001Formula A
A2N250 MF200/2400 FF 3P2TFG100132R1001Formula A
A2N250 TMF125/1250 FF 3P1SDA066781R1Formula A
A2N250 TMF125/1250 FF 3P + RCD+CT1102TFE100394R1001Formula A
A2N250 TMF125/1250 FF 4P1SDA066793R1Formula A
A2N250 TMF125/1250 FF 4P + RCD+CT1102TFE100401R1001Formula A
A2N250 TMF150/1500 FF 3P1SDA068781R1Formula A
A2N250 TMF150/1500 FF 3P + RCD+CT1102TFE100395R1001Formula A
A2N250 TMF150/1500 FF 4P1SDA068784R1Formula A
A2N250 TMF150/1500 FF 4P + RCD+CT1102TFE100402R1001Formula A
A2N250 TMF160/1600 FF 3P1SDA066782R1Formula A
A2N250 TMF160/1600 FF 3P + RCD+CT1102TFE100396R1001Formula A
A2N250 TMF160/1600 FF 4P1SDA066794R1Formula A
A2N250 TMF160/1600 FF 4P + RCD+CT1102TFE100403R1001Formula A
A2N250 TMF175/1750 FF 3P1SDA066783R1Formula A
A2N250 TMF175/1750 FF 3P + RCD+CT1102TFE100397R1001Formula A
A2N250 TMF175/1750 FF 4P1SDA066795R1Formula A
A2N250 TMF175/1750 FF 4P + RCD+CT1102TFE100404R1001Formula A
A2N250 TMF200/2000 FF 3P1SDA066784R1Formula A
A2N250 TMF200/2000 FF 3P + RCD+CT1102TFE100398R1001Formula A
A2N250 TMF200/2000 FF 4P1SDA066796R1Formula A
A2N250 TMF200/2000 FF 4P + RCD+CT1102TFE100405R1001Formula A
A2N250 TMF225/2250 FF 3P1SDA066785R1Formula A
A2N250 TMF225/2250 FF 3P + RCD+CT1102TFE100399R1001Formula A
A2N250 TMF225/2250 FF 4P1SDA066797R1Formula A
A2N250 TMF225/2250 FF 4P + RCD+CT1102TFE100406R1001Formula A
A2N250 TMF250/2500 FF 3P1SDA066786R1Formula A
A2N250 TMF250/2500 FF 3P + RCD+CT1102TFE100400R1001Formula A
A2N250 TMF250/2500 FF 4P1SDA066798R1Formula A
A2N250 TMF250/2500 FF 4P + RCD+CT1102TFE100407R1001Formula A
A3N400 MF250/3000 FF 3P2TFG100141R1001Formula A
A3N400 MF320/3840 FF 3P2TFG100142R1001Formula A
A3N400 TMF320/3200 FF 3P1SDA066560R1Formula A
A3N400 TMF320/3200 FF 3P + RCD+CT1852TFE100418R1001Formula A
A3N400 TMF320/3200 FF 4P + RCD+CT1852TFE100420R1001Formula A
A3N400 TMF320/3200 FF 4P N=100%1SDA066568R1Formula A
A3N400 TMF400/4000 FF 3P1SDA066561R1Formula A
A3N400 TMF400/4000 FF 3P + RCD+CT1852TFE100419R1001Formula A
A3N400 TMF400/4000 FF 4P + RCD+CT1852TFE100421R1001Formula A
A3N400 TMF400/4000 FF 4P N=100%1SDA066569R1Formula A
A3N630 ELT LI 630/6000 FF 3P + RCD+CT1852TFE100448R1001Formula A
A3N630 ELT LI 630/6000 FF 4P + RCD+CT1852TFE100449R1001Formula A
A3N630 ELT-I 500 FF 3P2TFG100144R1001Formula A
A3N630 ELT-LI R630 FF 3P1SDA066566R1Formula A
A3N630 ELT-LI R630 FF 4P1SDA066574R1Formula A
A3N630 MF400/4800 FF 3P2TFG100143R1001Formula A
A3N630 TMF500/5000 FF 3P1SDA066564R1Formula A
A3N630 TMF500/5000 FF 3P + RCD+CT1852TFE100446R1001Formula A
A3N630 TMF500/5000 FF 4P + RCD+CT1852TFE100447R1001Formula A
A3N630 TMF500/5000 FF 4P N=100%1SDA066572R1Formula A
A3S400 MF250/3000 FF 3P2TFG100145R1001Formula A
A3S400 MF320/3840 FF 3P2TFG100146R1001Formula A
A3S400 TMF320/3200 FF 3P1SDA066562R1Formula A
A3S400 TMF320/3200 FF 3P + RCD+CT1852TFE100432R1001Formula A
A3S400 TMF320/3200 FF 4P + RCD+CT1852TFE100434R1001Formula A
A3S400 TMF320/3200 FF 4P N=100%1SDA066570R1Formula A
A3S400 TMF400/4000 FF 3P1SDA066563R1Formula A
A3S400 TMF400/4000 FF 3P + RCD+CT1852TFE100433R1001Formula A
A3S400 TMF400/4000 FF 4P + RCD+CT1852TFE100435R1001Formula A
A3S400 TMF400/4000 FF 4P N=100%1SDA066571R1Formula A
A3S630 ELT LI 630/6000 FF 3P + RCD+CT1852TFE100462R1001Formula A
A3S630 ELT LI 630/6000 FF 4P + RCD+CT1852TFE100463R1001Formula A
A3S630 ELT-I 500 FF 3P2TFG100148R1001Formula A
A3S630 ELT-LI R630 FF 3P1SDA066567R1Formula A
A3S630 ELT-LI R630 FF 4P1SDA066575R1Formula A
A3S630 MF400/4800 FF 3P2TFG100147R1001Formula A
A3S630 TMF500/5000 FF 3P1SDA066565R1Formula A
A3S630 TMF500/5000 FF 3P + RCD+CT1852TFE100460R1001Formula A
A3S630 TMF500/5000 FF 4P + RCD+CT1852TFE100461R1001Formula A
A3S630 TMF500/5000 FF 4P N=100%1SDA066573R1Formula A

Downloads

Request a Quote

Request a Quote
