ABB F200 residual current circuit breakers (RCCBs) detect earth-fault current for residual current protection in residential, commercial and industrial installations. They do not include overload or short-circuit protection, so the circuit requires correctly selected overcurrent protection.
F200 selection depends on the residual-current waveform, poles, rated current and rated residual operating current. The existing model and ABB Order Code list below is a reference for identification and quotation; confirm the complete device specification before ordering.
RCCB Protection & Applications
F200 is used where residual current protection is required alongside an MCB or fuse. The RCCB rated current and its residual operating current serve different purposes: the former is its load-current rating, while IΔn identifies the residual-current operating threshold. Do not treat either value as an overload trip setting.
F200 Types & Application Boundaries
- Type AC: detects sinusoidal AC residual current. Confirm whether the load and local installation requirements permit this type.
- Type A: also detects pulsating DC residual current. It must not be treated as a device for detecting smooth DC fault current.
- Type F: ABB documents dedicated F200 Type F variants for loads such as single-phase frequency-converter applications. Their waveform and frequency performance must be checked in the Type F documentation; this does not change an AC or A reference into Type F.
- Type B: ABB documents F200 Type B for smooth DC and specified higher-frequency residual currents, including relevant converter, UPS and other power-electronic applications. Check the actual load and device limits.
- AP-R and selective S: immunity and time-delay characteristics are separate selection conditions. A selective upstream device is not a substitute for the required downstream additional protection.
The existing list contains F202 and F204 references, including AC, A, B and selective designations. ABB’s broader F200 offering also includes other variants; it does not establish that every type, pole count, current and sensitivity combination appears here.
Poles, Ratings & Standards
ABB documents two-pole and four-pole F200 variants. Its family overview gives rated currents from 16 to 125 A and sensitivities from 10 to 1000 mA, with availability dependent on the type and configuration. Use the exact model data rather than combining these ranges freely.
For example, ABB identifies F202 AC-25/0.03 / 2CSF202005R1250 as a 2-pole Type AC RCCB rated 25 A with 30 mA residual operating current. This example does not define other entries.
F200 RCCB documentation uses IEC/EN 61008; dedicated Type F and Type B documentation also identifies IEC/EN 62423. Check the exact standards and edition on the relevant declaration. Conditional short-circuit ratings depend on the specified protective device and must not be presented as an RCBO’s standalone breaking capacity. Regional approvals must be verified for the complete order code.
Choosing an F200 RCCB
Confirm the supply voltage and frequency, phases and neutral arrangement, poles, load current, IΔn, expected fault-current waveform and local protection requirements. Check time-delay/selectivity needs, upstream overload and short-circuit protection, installation conditions and neutral/test-circuit connections. For electronic loads, obtain the equipment manufacturer’s RCD requirement.
Related pages: Residual Current Protection category, MCB category and DS201 RCBOs with overcurrent protection. These are different protection arrangements, not a direct replacement statement.
ABB references: F200 overview; F200 Type B; F200 Type F technical data.
Existing Model References
F202 AC-25/0.03F202 AC-40/0.03F202 AC-63/0.03F202 A-40/0.03F204 AC-40/0.03F204 AC-63/0.03F204 A-40/0.03F204 A-63/0.03
ABB F200 Models & Order Codes
This existing list supports identification, not final protection design. Some legacy sensitivity/type fields require verification: a displayed sensitivity of 0 or “Other” is not a selectable rating or a confirmed RCD type. Confirm the complete model, Order Code and ABB data before ordering. Sensitivity is shown in amperes; 0.03 A equals 30 mA.
| Product Model | ABB Order Code | Poles | Rated Current (A) | Sensitivity (A) | Type |
|---|---|---|---|---|---|
| F202 AC-25/0.03 | 2CSF202005R1250 | 2 | 25 | 0.03 | AC |
| F202 AC-25/0.1 | 2CSF202005R2250 | 2 | 25 | 0.1 | AC |
| F202 AC-25/0.3 | 2CSF202005R3250 | 2 | 25 | 0.3 | AC |
| F202 AC-25/0.5 | 2CSF202005R4250 | 2 | 25 | 0.5 | AC |
| F202 AC-40/0.03 | 2CSF202005R1400 | 2 | 40 | 0.03 | AC |
| F202 AC-40/0.1 | 2CSF202005R2400 | 2 | 40 | 0.1 | AC |
| F202 AC-40/0.3 | 2CSF202005R3400 | 2 | 40 | 0.3 | AC |
| F202 AC-40/0.5 | 2CSF202005R4400 | 2 | 40 | 0.5 | AC |
| F202 AC-63/0.03 | 2CSF202005R1630 | 2 | 63 | 0.03 | AC |
| F202 AC-63/0.1 | 2CSF202005R2630 | 2 | 63 | 0.1 | AC |
| F202 AC-63/0.3 | 2CSF202005R3630 | 2 | 63 | 0.3 | AC |
| F202 AC-63/0.5 | 2CSF202005R4630 | 2 | 63 | 0.5 | AC |
| F202 AC-80/0.03 | 2CSF202005R1800 | 2 | 80 | 0.03 | AC |
| F202 AC-80/0.1 | 2CSF202005R2800 | 2 | 80 | 0.1 | AC |
| F202 AC-80/0.3 | 2CSF202005R3800 | 2 | 80 | 0.3 | AC |
| F202 AC-80/0.5 | 2CSF202005R4800 | 2 | 80 | 0.5 | AC |
| F202 AC-100/0.03 | 2CSF202005R1900 | 2 | 100 | 0.03 | AC |
| F202 AC-100/0.1 | 2CSF202005R2900 | 2 | 100 | 0.1 | AC |
| F202 AC-100/0.3 | 2CSF202005R3900 | 2 | 100 | 0.3 | AC |
| F202 AC-100/0.5 | 2CSF202005R4900 | 2 | 100 | 0.5 | AC |
| F204 AC-25/0.03 | 2CSF204005R1250 | 4 | 25 | 0.03 | AC |
| F204 AC-25/0.1 | 2CSF204005R2250 | 4 | 25 | 0.1 | AC |
| F204 AC-25/0.3 | 2CSF204005R3250 | 4 | 25 | 0.3 | AC |
| F204 AC-25/0.5 | 2CSF204005R4250 | 4 | 25 | 0.5 | AC |
| F204 AC-40/0.03 | 2CSF204005R1400 | 4 | 40 | 0.03 | AC |
| F204 AC-40/0.1 | 2CSF204005R2400 | 4 | 40 | 0.1 | AC |
| F204 AC-40/0.3 | 2CSF204005R3400 | 4 | 40 | 0.3 | AC |
| F204 AC-40/0.5 | 2CSF204005R4400 | 4 | 40 | 0.5 | AC |
| F204 AC-63/0.03 | 2CSF204005R1630 | 4 | 63 | 0.03 | AC |
| F204 AC-63/0.1 | 2CSF204005R2630 | 4 | 63 | 0.1 | AC |
| F204 AC-63/0.3 | 2CSF204005R3630 | 4 | 63 | 0.3 | AC |
| F204 AC-63/0.5 | 2CSF204005R4630 | 4 | 63 | 0.5 | AC |
| F204 AC-80/0.03 | 2CSF204005R1800 | 4 | 80 | 0.03 | AC |
| F204 AC-80/0.1 | 2CSF204005R2800 | 4 | 80 | 0.1 | AC |
| F204 AC-80/0.3 | 2CSF204005R3800 | 4 | 80 | 0.3 | AC |
| F204 AC-80/0.5 | 2CSF204005R4800 | 4 | 80 | 0.5 | AC |
| F204 AC-100/0.03 | 2CSF204005R1900 | 4 | 100 | 0.03 | AC |
| F204 AC-100/0.1 | 2CSF204005R2900 | 4 | 100 | 0.1 | AC |
| F204 AC-100/0.3 | 2CSF204005R3900 | 4 | 100 | 0.3 | AC |
| F204 AC-100/0.5 | 2CSF204005R4900 | 4 | 100 | 0.5 | AC |
| F202 A-16/0.01 | 2CSF202101R0160 | 2 | 16 | 0.01 | A |
| F202 A-25/0.03 | 2CSF202101R1250 | 2 | 25 | 0.03 | A |
| F202 A-25/0.03 110V | 2CSF202199R1250 | 2 | 25 | 0.03 | A |
| F202 A-25/0.1 | 2CSF202101R2250 | 2 | 25 | 0.1 | A |
| F202 A-25/0.3 | 2CSF202101R3250 | 2 | 25 | 0.3 | A |
| F202 A-25/0.5 | 2CSF202101R4250 | 2 | 25 | 0.5 | A |
| F202 A-40/0.03 | 2CSF202101R1400 | 2 | 40 | 0.03 | A |
| F202 A-40/0.03 110V | 2CSF202199R1400 | 2 | 40 | 0.03 | A |
| F202 A-40/0.1 | 2CSF202101R2400 | 2 | 40 | 0.1 | A |
| F202 A-40/0.3 | 2CSF202101R3400 | 2 | 40 | 0.3 | A |
| F202 A-40/0.5 | 2CSF202101R4400 | 2 | 40 | 0.5 | A |
| F202 A-63/0.03 | 2CSF202101R1630 | 2 | 63 | 0.03 | A |
| F202 A-63/0.03 110V | 2CSF202199R1630 | 2 | 63 | 0.03 | A |
| F202 A-63/0.1 | 2CSF202101R2630 | 2 | 63 | 0.1 | A |
| F202 A-63/0.3 | 2CSF202101R3630 | 2 | 63 | 0.3 | A |
| F202 A-63/0.5 | 2CSF202101R4630 | 2 | 63 | 0.5 | A |
| F202 A-80/0.03 | 2CSF202101R1800 | 2 | 80 | 0.03 | A |
| F202 A-80/0.03 110V | 2CSF202199R1800 | 2 | 80 | 0.03 | A |
| F202 A-80/0.1 | 2CSF202101R2800 | 2 | 80 | 0.1 | A |
| F202 A-80/0.3 | 2CSF202101R3800 | 2 | 80 | 0.3 | A |
| F202 A-80/0.5 | 2CSF202101R4800 | 2 | 80 | 0.5 | A |
| F202 A-100/0.03 | 2CSF202101R1900 | 2 | 100 | 0.03 | A |
| F202 A-100/0.03 110V | 2CSF202199R1100 | 2 | 100 | 0.03 | A |
| F202 A-100/0.1 | 2CSF202101R2900 | 2 | 100 | 0.1 | A |
| F202 A-100/0.3 | 2CSF202101R3900 | 2 | 100 | 0.3 | A |
| F202 A-100/0.5 | 2CSF202101R4900 | 2 | 100 | 0.5 | A |
| F204 A-25/0.03 | 2CSF204101R1250 | 4 | 25 | 0.03 | A |
| F204 A-25/0.03 110V | 2CSF204199R1250 | 4 | 25 | 0.03 | A |
| F204 A-25/0.03-L | 2CSF204123R1250 | 4 | 25 | 0.03 | A |
| F204 A-25/0.1 | 2CSF204101R2250 | 4 | 25 | 0.1 | A |
| F204 A-25/0.1-L | 2CSF204123R2250 | 4 | 25 | 0.1 | A |
| F204 A-25/0.3 | 2CSF204101R3250 | 4 | 25 | 0.3 | A |
| F204 A-25/0.3-L | 2CSF204123R3250 | 4 | 25 | 0.3 | A |
| F204 A-25/0.5 | 2CSF204101R4250 | 4 | 25 | 0.5 | A |
| F204 A-25/0.5-L | 2CSF204123R4250 | 4 | 25 | 0.5 | A |
| F204 A-40/0.03 | 2CSF204101R1400 | 4 | 40 | 0.03 | A |
| F204 A-40/0.03 110V | 2CSF204199R1400 | 4 | 40 | 0.03 | A |
| F204 A-40/0.03-L | 2CSF204123R1400 | 4 | 40 | 0.03 | A |
| F204 A-40/0.1 | 2CSF204101R2400 | 4 | 40 | 0.1 | A |
| F204 A-40/0.1-L | 2CSF204123R2400 | 4 | 40 | 0.1 | A |
| F204 A-40/0.3 | 2CSF204101R3400 | 4 | 40 | 0.3 | A |
| F204 A-40/0.3-L | 2CSF204123R3400 | 4 | 40 | 0.3 | A |
| F204 A-40/0.5 | 2CSF204101R4400 | 4 | 40 | 0.5 | A |
| F204 A-40/0.5-L | 2CSF204123R4400 | 4 | 40 | 0.5 | A |
| F204 A-63/0.03 | 2CSF204101R1630 | 4 | 63 | 0.03 | A |
| F204 A-63/0.03 110V | 2CSF204199R1630 | 4 | 63 | 0.03 | A |
| F204 A-63/0.03-L | 2CSF204123R1630 | 4 | 63 | 0.03 | A |
| F204 A-63/0.1 | 2CSF204101R2630 | 4 | 63 | 0.1 | A |
| F204 A-63/0.1-L | 2CSF204123R2630 | 4 | 63 | 0.1 | A |
| F204 A-63/0.3 | 2CSF204101R3630 | 4 | 63 | 0.3 | A |
| F204 A-63/0.3-L | 2CSF204123R3630 | 4 | 63 | 0.3 | A |
| F204 A-63/0.5 | 2CSF204101R4630 | 4 | 63 | 0.5 | A |
| F204 A-63/0.5-L | 2CSF204123R4630 | 4 | 63 | 0.5 | A |
| F204 A-80/0.03 | 2CSF204101R1800 | 4 | 80 | 0.03 | A |
| F204 A-80/0.03 110V | 2CSF204199R1800 | 4 | 80 | 0.03 | A |
| F204 A-80/0.03-L | 2CSF204123R1800 | 4 | 80 | 0.03 | A |
| F204 A-80/0.1 | 2CSF204101R2800 | 4 | 80 | 0.1 | A |
| F204 A-80/0.3 | 2CSF204101R3800 | 4 | 80 | 0.3 | A |
| F204 A-80/0.3-L | 2CSF204123R3800 | 4 | 80 | 0.3 | A |
| F204 A-80/0.5 | 2CSF204101R4800 | 4 | 80 | 0.5 | A |
| F204 A-100/0.03 | 2CSF204101R1900 | 4 | 100 | 0.03 | A |
| F204 A-100/0.03 110V | 2CSF204199R1100 | 4 | 100 | 0.03 | A |
| F204 A-100/0.03-L | 2CSF204123R1900 | 4 | 100 | 0.03 | A |
| F204 A-100/0.1 | 2CSF204101R2900 | 4 | 100 | 0.1 | A |
| F204 A-100/0.3 | 2CSF204101R3900 | 4 | 100 | 0.3 | A |
| F204 A-100/0.3-L | 2CSF204123R3900 | 4 | 100 | 0.3 | A |
| F204 A-100/0.5 | 2CSF204101R4900 | 4 | 100 | 0.5 | A |
| F202 A S-40/0.1 | 2CSF202201R2400 | 2 | 40 | 0.1 | A Selective |
| F202 A S-40/0.3 | 2CSF202201R3400 | 2 | 40 | 0.3 | A Selective |
| F202 A S-40/0.5 | 2CSF202201R4400 | 2 | 40 | 0.5 | A Selective |
| F202 A S-40/1 | 2CSF202201R5400 | 2 | 40 | 1 | A Selective |
| F202 A S-63/0.1 | 2CSF202201R2630 | 2 | 63 | 0.1 | A Selective |
| F202 A S-63/0.3 | 2CSF202201R3630 | 2 | 63 | 0.3 | A Selective |
| F202 A S-63/0.5 | 2CSF202201R4630 | 2 | 63 | 0.5 | A Selective |
| F202 A S-63/1 | 2CSF202201R5630 | 2 | 63 | 1 | A Selective |
| F202 A S-100/0.1 | 2CSF202201R2900 | 2 | 100 | 0.1 | A Selective |
| F202 A S-100/0.3 | 2CSF202201R3900 | 2 | 100 | 0.3 | A Selective |
| F202 A S-100/0.5 | 2CSF202201R4900 | 2 | 100 | 0.5 | A Selective |
| F202 A S-100/1 | 2CSF202201R5900 | 2 | 100 | 1 | A Selective |
| F204 A S-40/0.1 | 2CSF204201R2400 | 4 | 40 | 0.1 | A Selective |
| F204 A S-40/0.3 | 2CSF204201R3400 | 4 | 40 | 0.3 | A Selective |
| F204 A S-40/0.5 | 2CSF204201R4400 | 4 | 40 | 0.5 | A Selective |
| F204 A S-40/1 | 2CSF204201R5400 | 4 | 40 | 1 | A Selective |
| F204 A S-63/0.1 | 2CSF204201R2630 | 4 | 63 | 0.1 | A Selective |
| F204 A S-63/0.3 | 2CSF204201R3630 | 4 | 63 | 0.3 | A Selective |
| F204 A S-63/0.5 | 2CSF204201R4630 | 4 | 63 | 0.5 | A Selective |
| F204 A S-63/1 | 2CSF204201R5630 | 4 | 63 | 1 | A Selective |
| F204 A S-100/0.1 | 2CSF204201R2900 | 4 | 100 | 0.1 | A Selective |
| F204 A S-100/0.3 | 2CSF204201R3900 | 4 | 100 | 0.3 | A Selective |
| F204 A S-100/0.5 | 2CSF204201R4900 | 4 | 100 | 0.5 | A Selective |
| F204 A S-100/1 | 2CSF204201R5900 | 4 | 100 | 1 | A Selective |
| F202 A-25/0.03 AP-R | 2CSF202401R1250 | 2 | 25 | 0.03 | A-APR |
| F202 A-40/0.03 AP-R | 2CSF202401R1400 | 2 | 40 | 0.03 | A-APR |
| F202 A-63/0.03 AP-R | 2CSF202401R1630 | 2 | 63 | 0.03 | A-APR |
| F202 A-80/0.03 AP-R | 2CSF202401R1800 | 2 | 80 | 0.03 | A-APR |
| F202 A-100/0.03 AP-R | 2CSF202401R1900 | 2 | 100 | 0.03 | A-APR |
| F204 A-25/0.03 AP-R | 2CSF204401R1250 | 4 | 25 | 0.03 | A-APR |
| F204 A-40/0.03 AP-R | 2CSF204401R1400 | 4 | 40 | 0.03 | A-APR |
| F204 A-63/0.03 AP-R | 2CSF204401R1630 | 4 | 63 | 0.03 | A-APR |
| F204 A-80/0.03 AP-R | 2CSF204401R1800 | 4 | 80 | 0.03 | A-APR |
| F204 A-100/0.03 AP-R | 2CSF204401R1900 | 4 | 100 | 0.03 | A-APR |
| F202 B-16/0.03 | 2CSF202568R1160 | 2 | 16 | 0.03 | B |
| F202 B-16/0.3 | 2CSF202568R3160 | 2 | 16 | 0.3 | B |
| F202 B-25/0.03 | 2CSF202568R1250 | 2 | 25 | 0.03 | B |
| F202 B-25/0.3 | 2CSF202568R3250 | 2 | 25 | 0.3 | B |
| F202 B-40/0.03 | 2CSF202568R1400 | 2 | 40 | 0.03 | B |
| F202 B-40/0.3 | 2CSF202568R3400 | 2 | 40 | 0.3 | B |
| F202 B-63/0.03 | 2CSF202568R1630 | 2 | 63 | 0.03 | B |
| F202 B-63/0.3 | 2CSF202568R3630 | 2 | 63 | 0.3 | B |
| F204 B-25/0.03 | 2CSF204568R1250 | 4 | 25 | 0.03 | B |
| F204 B-25/0.3 | 2CSF204568R3250 | 4 | 25 | 0.3 | B |
| F204 B-40/0,03 | 2CSF204592R1400 | 4 | 40 | 0 | B |
| F204 B-40/0,5 | 2CSF204592R4400 | 4 | 40 | 0 | B |
| F204 B-40/0.03 | 2CSF204568R1400 | 4 | 40 | 0.03 | B |
| F204 B-40/0.3 | 2CSF204568R3400 | 4 | 40 | 0.3 | B |
| F204 B-63/0,5 | 2CSF204592R4630 | 4 | 63 | 0 | B |
| F204 B-63/0.03 | 2CSF204568R1630 | 4 | 63 | 0.03 | B |
| F204 B-63/0.3 | 2CSF204568R3630 | 4 | 63 | 0.3 | B |
| F204 B S-40/0,5 | 2CSF204892R4400 | 4 | 40 | 0 | Other |
| F204 B S-40/0.3 | 2CSF204868R3400 | 4 | 40 | 0.3 | Other |
| F204 B S-63/0,5 | 2CSF204892R4630 | 4 | 63 | 0 | Other |
| F204 B S-63/0.3 | 2CSF204868R3630 | 4 | 63 | 0.3 | Other |
Request an F200 Quote
Send the full model, ABB Order Code / Article Number, quantity and destination country. For selection support, include supply voltage and frequency, phases/neutral, poles, rated current, required IΔn and RCD type, load details, selectivity needs and upstream protective device. Add a nameplate photo for an existing installation.
