ABB ACH580 drives are designed for HVACR applications, while ACQ580 drives address water and wastewater pump control. The existing combined lookup table contains both families. Their application software and configuration requirements must be evaluated separately; a shared drive architecture does not make their complete models interchangeable.
ABB ACH580 & ACQ580 Series
Key Features
ACH580: HVACR systems
ACH580 supports motor-driven heating, ventilation, air-conditioning and refrigeration equipment. Fan, pump and compressor applications have different motor, operating and control requirements. Confirm the applicable HVAC control program, building-management interface and installation form for the specified drive.
ACQ580: water and wastewater
ACQ580 is intended for water and wastewater pumping. ABB describes pump-oriented functions such as dry-run protection, pump cleaning and anti-cavitation control. The availability and configuration of these functions must be checked in the applicable pump-control firmware manual; they are not stated as universal ACH580 functions.
Installation and electrical selection
ABB documents wall-mounted units, cabinet-integration modules and cabinet-built configurations within these families, with separate ultra-low harmonic variants. Enclosure classes, power/current ratings and supply ranges depend on the complete model and options. Do not transfer a maximum catalogue value or a US bypass-package rating to every IEC reference.
- Provide the motor nameplate data, supply voltage/frequency and actual load duty.
- Identify HVACR or water/wastewater service and the required process-control functions.
- Specify installation form, enclosure, ambient temperature, altitude, cooling and available space.
- Confirm building-management or PLC protocol, I/O, sensors and the applicable control-program version.
- For pump selection, include pump characteristics, pressure/flow requirements and the planned operating arrangement.
- For harmonic, braking, EMC or safety requirements, verify the specific hardware and installation conditions rather than assuming them from the family name.
Full-code and version checks
The existing table contains 86 ACH580 and 86 ACQ580 references. All models, option suffixes and codes are retained. IEC and UL/NEMA variants must be checked against their own documentation; historical references are not assigned current-version ratings or inferred replacement relationships.
Information for quotation
Send the full drive model and ABB code, quantity and destination country. Include motor data, supply, application, enclosure and required controls/options. For an existing installation, add nameplate photos and firmware/control information. Product status and current availability should be confirmed before ordering.
Browse Variable Frequency Drives, Drive Accessories, or Contact. Official product references: ABB ACH580 HVACR drives and ABB ACQ580 water and wastewater drives. The retained download below covers ACH580 HVACR; ACQ580 requires its own applicable documentation.
Popular Models
ACH580
- ACH580-01-04A1-4
- ACH580-01-06A9-4
- ACH580-01-09A5-4
- ACH580-01-12A7-4
- ACH580-01-018A-4
- ACH580-01-031A-4
ACQ580
- ACQ580-01-04A1-4
- ACQ580-01-06A9-4
- ACQ580-01-09A5-4
- ACQ580-01-12A7-4
- ACQ580-01-018A-4
- ACQ580-01-031A-4
ABB ACH580 & ACQ580 Complete Model List
Browse ACH580 drives for HVAC applications and ACQ580 drives for water and wastewater applications. Search by model number or vendor code, or filter by product family and series.
172 models found
| Product Family | Series | Model | Vendor Code |
|---|---|---|---|
| ACH580 | ACH580-01 | ACH580-01-018A-4 | 3ABD50000038993 |
| ACH580 | ACH580-01 | ACH580-01-018A-4+B056 | 3ABD50000039010 |
| ACH580 | ACH580-01 | ACH580-01-026A-4 | 3ABD50000038994 |
| ACH580 | ACH580-01 | ACH580-01-026A-4+B056 | 3ABD50000039011 |
| ACH580 | ACH580-01 | ACH580-01-02A7-4 | 3ABD50000038981 |
| ACH580 | ACH580-01 | ACH580-01-02A7-4+B056 | 3ABD50000038998 |
| ACH580 | ACH580-01 | ACH580-01-033A-4 | 3ABD50000038995 |
| ACH580 | ACH580-01 | ACH580-01-033A-4+B056 | 3ABD50000039012 |
| ACH580 | ACH580-01 | ACH580-01-039A-4 | 3ABD50000038996 |
| ACH580 | ACH580-01 | ACH580-01-039A-4+B056 | 3ABD50000039013 |
| ACH580 | ACH580-01 | ACH580-01-03A4-4 | 3ABD50000038982 |
| ACH580 | ACH580-01 | ACH580-01-03A4-4+B056 | 3ABD50000038999 |
| ACH580 | ACH580-01 | ACH580-01-046A-4 | 3ABD50000038997 |
| ACH580 | ACH580-01 | ACH580-01-046A-4+B056 | 3ABD50000039014 |
| ACH580 | ACH580-01 | ACH580-01-04A1-4 | 3ABD50000038983 |
| ACH580 | ACH580-01 | ACH580-01-04A1-4+B056 | 3ABD50000039000 |
| ACH580 | ACH580-01 | ACH580-01-05A7-4 | 3ABD50000038984 |
| ACH580 | ACH580-01 | ACH580-01-05A7-4+B056 | 3ABD50000039001 |
| ACH580 | ACH580-01 | ACH580-01-062A-4 | 3ABD00045411-D |
| ACH580 | ACH580-01 | ACH580-01-062A-4+B056 | 3ABD00045700-D |
| ACH580 | ACH580-01 | ACH580-01-073A-4 | 3ABD00045412-D |
| ACH580 | ACH580-01 | ACH580-01-073A-4+B056 | 3ABD00045701-D |
| ACH580 | ACH580-01 | ACH580-01-07A3-4 | 3ABD50000038985 |
| ACH580 | ACH580-01 | ACH580-01-07A3-4+B056 | 3ABD50000039002 |
| ACH580 | ACH580-01 | ACH580-01-089A-4 | 3ABD00060196-D |
| ACH580 | ACH580-01 | ACH580-01-089A-4+B056 | 3ABD00060197-D |
| ACH580 | ACH580-01 | ACH580-01-09A5-4 | 3ABD50000038986 |
| ACH580 | ACH580-01 | ACH580-01-09A5-4+B056 | 3ABD50000039003 |
| ACH580 | ACH580-01 | ACH580-01-106A-4 | 3ABD00045414-D |
| ACH580 | ACH580-01 | ACH580-01-106A-4+B056 | 3ABD00045703-D |
| ACH580 | ACH580-01 | ACH580-01-12A7-4 | 3ABD50000038987 |
| ACH580 | ACH580-01 | ACH580-01-12A7-4+B056 | 3ABD50000039004 |
| ACH580 | ACH580-01 | ACH580-01-145A-4 | 3ABD00045415-D |
| ACH580 | ACH580-01 | ACH580-01-145A-4+B056 | 3ABD00045704-D |
| ACH580 | ACH580-01 | ACH580-01-169A-4 | 3ABD00045416-D |
| ACH580 | ACH580-01 | ACH580-01-169A-4+B056 | 3ABD00045705-D |
| ACH580 | ACH580-01 | ACH580-01-206A-4 | 3ABD00045417-D |
| ACH580 | ACH580-01 | ACH580-01-206A-4+B056 | 3ABD00045706-D |
| ACH580 | ACH580-01 | ACH580-01-246A-4 | 3ABD00045418-D |
| ACH580 | ACH580-01 | ACH580-01-246A-4+B056 | 3ABD00045707-D |
| ACH580 | ACH580-01 | ACH580-01-293A-4 | 3ABD00045419-D |
| ACH580 | ACH580-01 | ACH580-01-293A-4+B056 | 3ABD00045708-D |
| ACH580 | ACH580-01 | ACH580-01-363A-4 | 3ABD00045420-D |
| ACH580 | ACH580-01 | ACH580-01-363A-4+B056 | 3ABD00045709-D |
| ACH580 | ACH580-01 | ACH580-01-430A-4 | 3ABD00045421-D |
| ACH580 | ACH580-01 | ACH580-01-430A-4+B056 | 3ABD00045710-D |
| ACH580 | ACH580-04 | ACH580-04-505A-4 | 3ABD00046068-D |
| ACH580 | ACH580-04 | ACH580-04-585A-4 | 3ABD00046069-D |
| ACH580 | ACH580-04 | ACH580-04-650A-4 | 3ABD00046070-D |
| ACH580 | ACH580-04 | ACH580-04-725A-4 | 3ABD00046071-D |
| ACH580 | ACH580-04 | ACH580-04-820A-4 | 3ABD00046072-D |
| ACH580 | ACH580-04 | ACH580-04-880A-4 | 3ABD00046073-D |
| ACH580 | ACH580-07 | ACH580-07-0145A-4 | — |
| ACH580 | ACH580-07 | ACH580-07-0169A-4 | — |
| ACH580 | ACH580-07 | ACH580-07-0206A-4 | — |
| ACH580 | ACH580-07 | ACH580-07-0246A-4 | — |
| ACH580 | ACH580-07 | ACH580-07-0293A-4 | — |
| ACH580 | ACH580-07 | ACH580-07-0363A-4 | — |
| ACH580 | ACH580-07 | ACH580-07-0430A-4 | — |
| ACH580 | ACH580-07 | ACH580-07-0505A-4 | — |
| ACH580 | ACH580-07 | ACH580-07-0585A-4 | — |
| ACH580 | ACH580-07 | ACH580-07-0650A-4 | — |
| ACH580 | ACH580-07 | ACH580-07-0725A-4 | — |
| ACH580 | ACH580-07 | ACH580-07-0820A-4 | — |
| ACH580 | ACH580-07 | ACH580-07-0880A-4 | — |
| ACH580 | ACH580-31 | ACH580-31-018A-4 | — |
| ACH580 | ACH580-31 | ACH580-31-026A-4 | — |
| ACH580 | ACH580-31 | ACH580-31-033A-4 | — |
| ACH580 | ACH580-31 | ACH580-31-039A-4 | — |
| ACH580 | ACH580-31 | ACH580-31-046A-4 | — |
| ACH580 | ACH580-31 | ACH580-31-062A-4 | — |
| ACH580 | ACH580-31 | ACH580-31-073A-4 | — |
| ACH580 | ACH580-31 | ACH580-31-088A-4 | — |
| ACH580 | ACH580-31 | ACH580-31-09A5-4 | — |
| ACH580 | ACH580-31 | ACH580-31-106A-4 | — |
| ACH580 | ACH580-31 | ACH580-31-12A7-4 | — |
| ACH580 | ACH580-31 | ACH580-31-145A-4 | — |
| ACH580 | ACH580-31 | ACH580-31-169A-4 | — |
| ACH580 | ACH580-31 | ACH580-31-206A-4 | — |
| ACH580 | ACH580-34 | ACH580-34-246A-4 | — |
| ACH580 | ACH580-34 | ACH580-34-293A-4 | — |
| ACH580 | ACH580-34 | ACH580-34-365A-4 | — |
| ACH580 | ACH580-34 | ACH580-34-442A-4 | — |
| ACH580 | ACH580-34 | ACH580-34-505A-4 | — |
| ACH580 | ACH580-34 | ACH580-34-585A-4 | — |
| ACH580 | ACH580-34 | ACH580-34-650A-4 | — |
| ACQ580 | ACQ580-01 | ACQ580-01-018A-4 | 3ABD50000039027 |
| ACQ580 | ACQ580-01 | ACQ580-01-018A-4+B056 | 3ABD50000039044 |
| ACQ580 | ACQ580-01 | ACQ580-01-026A-4 | 3ABD50000039028 |
| ACQ580 | ACQ580-01 | ACQ580-01-026A-4+B056 | 3ABD50000039045 |
| ACQ580 | ACQ580-01 | ACQ580-01-02A7-4 | 3ABD50000039015 |
| ACQ580 | ACQ580-01 | ACQ580-01-02A7-4+B056 | 3ABD50000039032 |
| ACQ580 | ACQ580-01 | ACQ580-01-033A-4 | 3ABD50000039029 |
| ACQ580 | ACQ580-01 | ACQ580-01-033A-4+B056 | 3ABD50000039046 |
| ACQ580 | ACQ580-01 | ACQ580-01-039A-4 | 3ABD50000039030 |
| ACQ580 | ACQ580-01 | ACQ580-01-039A-4+B056 | 3ABD50000039047 |
| ACQ580 | ACQ580-01 | ACQ580-01-03A4-4 | 3ABD50000039016 |
| ACQ580 | ACQ580-01 | ACQ580-01-03A4-4+B056 | 3ABD50000039033 |
| ACQ580 | ACQ580-01 | ACQ580-01-046A-4 | 3ABD50000039031 |
| ACQ580 | ACQ580-01 | ACQ580-01-046A-4+B056 | 3ABD50000039048 |
| ACQ580 | ACQ580-01 | ACQ580-01-04A1-4 | 3ABD50000039017 |
| ACQ580 | ACQ580-01 | ACQ580-01-04A1-4+B056 | 3ABD50000039034 |
| ACQ580 | ACQ580-01 | ACQ580-01-05A7-4 | 3ABD50000039018 |
| ACQ580 | ACQ580-01 | ACQ580-01-05A7-4+B056 | 3ABD50000039035 |
| ACQ580 | ACQ580-01 | ACQ580-01-062A-4 | 3ABD00045422-D |
| ACQ580 | ACQ580-01 | ACQ580-01-062A-4+B056 | 3ABD00045723-D |
| ACQ580 | ACQ580-01 | ACQ580-01-073A-4 | 3ABD00045423-D |
| ACQ580 | ACQ580-01 | ACQ580-01-073A-4+B056 | 3ABD00045724-D |
| ACQ580 | ACQ580-01 | ACQ580-01-07A3-4 | 3ABD50000039019 |
| ACQ580 | ACQ580-01 | ACQ580-01-07A3-4+B056 | 3ABD50000039036 |
| ACQ580 | ACQ580-01 | ACQ580-01-089A-4 | 3ABD00060201-D |
| ACQ580 | ACQ580-01 | ACQ580-01-089A-4+B056 | 3ABD00060202-D |
| ACQ580 | ACQ580-01 | ACQ580-01-09A5-4 | 3ABD50000039020 |
| ACQ580 | ACQ580-01 | ACQ580-01-09A5-4+B056 | 3ABD50000039037 |
| ACQ580 | ACQ580-01 | ACQ580-01-106A-4 | 3ABD00045425-D |
| ACQ580 | ACQ580-01 | ACQ580-01-106A-4+B056 | 3ABD00045726-D |
| ACQ580 | ACQ580-01 | ACQ580-01-12A7-4 | 3ABD50000039021 |
| ACQ580 | ACQ580-01 | ACQ580-01-12A7-4+B056 | 3ABD50000039038 |
| ACQ580 | ACQ580-01 | ACQ580-01-145A-4 | 3ABD00045426-D |
| ACQ580 | ACQ580-01 | ACQ580-01-145A-4+B056 | 3ABD00045727-D |
| ACQ580 | ACQ580-01 | ACQ580-01-169A-4 | 3ABD00045427-D |
| ACQ580 | ACQ580-01 | ACQ580-01-169A-4+B056 | 3ABD00045728-D |
| ACQ580 | ACQ580-01 | ACQ580-01-206A-4 | 3ABD00045428-D |
| ACQ580 | ACQ580-01 | ACQ580-01-206A-4+B056 | 3ABD00045729-D |
| ACQ580 | ACQ580-01 | ACQ580-01-246A-4 | 3ABD00045429-D |
| ACQ580 | ACQ580-01 | ACQ580-01-246A-4+B056 | 3ABD00045730-D |
| ACQ580 | ACQ580-01 | ACQ580-01-293A-4 | 3ABD00045430-D |
| ACQ580 | ACQ580-01 | ACQ580-01-293A-4+B056 | 3ABD00045731-D |
| ACQ580 | ACQ580-01 | ACQ580-01-363A-4 | 3ABD00045431-D |
| ACQ580 | ACQ580-01 | ACQ580-01-363A-4+B056 | 3ABD00045732-D |
| ACQ580 | ACQ580-01 | ACQ580-01-430A-4 | 3ABD00045432-D |
| ACQ580 | ACQ580-01 | ACQ580-01-430A-4+B056 | 3ABD00045733-D |
| ACQ580 | ACQ580-04 | ACQ580-04-505A-4 | 3ABD00046074-D |
| ACQ580 | ACQ580-04 | ACQ580-04-585A-4 | 3ABD00046075-D |
| ACQ580 | ACQ580-04 | ACQ580-04-650A-4 | 3ABD00046076-D |
| ACQ580 | ACQ580-04 | ACQ580-04-725A-4 | 3ABD00046077-D |
| ACQ580 | ACQ580-04 | ACQ580-04-820A-4 | 3ABD00046078-D |
| ACQ580 | ACQ580-04 | ACQ580-04-880A-4 | 3ABD00046079-D |
| ACQ580 | ACQ580-07 | ACQ580-07-0145A-4 | — |
| ACQ580 | ACQ580-07 | ACQ580-07-0169A-4 | — |
| ACQ580 | ACQ580-07 | ACQ580-07-0206A-4 | — |
| ACQ580 | ACQ580-07 | ACQ580-07-0246A-4 | — |
| ACQ580 | ACQ580-07 | ACQ580-07-0293A-4 | — |
| ACQ580 | ACQ580-07 | ACQ580-07-0363A-4 | — |
| ACQ580 | ACQ580-07 | ACQ580-07-0430A-4 | — |
| ACQ580 | ACQ580-07 | ACQ580-07-0505A-4 | — |
| ACQ580 | ACQ580-07 | ACQ580-07-0585A-4 | — |
| ACQ580 | ACQ580-07 | ACQ580-07-0650A-4 | — |
| ACQ580 | ACQ580-07 | ACQ580-07-0725A-4 | — |
| ACQ580 | ACQ580-07 | ACQ580-07-0820A-4 | — |
| ACQ580 | ACQ580-07 | ACQ580-07-0880A-4 | — |
| ACQ580 | ACQ580-31 | ACQ580-31-018A-4 | — |
| ACQ580 | ACQ580-31 | ACQ580-31-026A-4 | — |
| ACQ580 | ACQ580-31 | ACQ580-31-033A-4 | — |
| ACQ580 | ACQ580-31 | ACQ580-31-039A-4 | — |
| ACQ580 | ACQ580-31 | ACQ580-31-046A-4 | — |
| ACQ580 | ACQ580-31 | ACQ580-31-062A-4 | — |
| ACQ580 | ACQ580-31 | ACQ580-31-073A-4 | — |
| ACQ580 | ACQ580-31 | ACQ580-31-088A-4 | — |
| ACQ580 | ACQ580-31 | ACQ580-31-09A5-4 | — |
| ACQ580 | ACQ580-31 | ACQ580-31-106A-4 | — |
| ACQ580 | ACQ580-31 | ACQ580-31-12A7-4 | — |
| ACQ580 | ACQ580-31 | ACQ580-31-145A-4 | — |
| ACQ580 | ACQ580-31 | ACQ580-31-169A-4 | — |
| ACQ580 | ACQ580-31 | ACQ580-31-206A-4 | — |
| ACQ580 | ACQ580-34 | ACQ580-34-246A-4 | — |
| ACQ580 | ACQ580-34 | ACQ580-34-293A-4 | — |
| ACQ580 | ACQ580-34 | ACQ580-34-365A-4 | — |
| ACQ580 | ACQ580-34 | ACQ580-34-442A-4 | — |
| ACQ580 | ACQ580-34 | ACQ580-34-505A-4 | — |
| ACQ580 | ACQ580-34 | ACQ580-34-585A-4 | — |
| ACQ580 | ACQ580-34 | ACQ580-34-650A-4 | — |
